Gazzella ATLANTIQUE
Reinforced cardboard box making machine/Automatic Stitcher – Gluer

The latest integrated stitcher and gluer machine improves productivity and reduces manpower

GazzeLLa's reinforced cardboard box making machine has an equipment of the latest functions that combines a stitcher and a gluer. Its unparalleled high-speed stitching improves productivity, and its well-designed side stopper system makes it easy to set up and perform paper feeding operations that were previously difficult for non-experts. If a stacker is installed, sheets can be automatically stacked and organized, reducing the number of workers required.

TO6400／SEMI-AUTOMATIC STITCHER- GLUER

TO6400 is a semi-automatic stitcher-gluer that can handle single and double wall corrugated board. It has equipment of a high-speed stitching device that can handle 700 stitches per minute and a gluer, so it can stitch and glue with one machine. In addition, by installing a stacker, sheets can be automatically stacked and organized without the need for an operator on the delivery side.

≪Specification≫

Single, Double wall corrugated board
One- or Two-pieces box
700 stitches per minute
450～750 boxes per hour
Hot melt gluing, PVA gluing, Mixed
Taping

Height adjustable table

Ejector

Semi-automatic feeder

Stacker

High-speed stitching device

Glue Device

Machine size (mm)

Reinforced cardboard processing size range (mm)

TW7200／SEMI-AUTOMATIC STITCHER- GLUER

TW7200 is a semi-automatic stitcher-gluer that can handle single, double, and triple wall corrugated board. It has equipment of a high-speed stitching device that can handle 1400 stitches per minute and a glueing device, it can stitch and glue on one machine. In addition, by installing a stacker, sheets can be automatically stacked and organized without the need for an operator on the delivery side.

≪Specification≫

Single, Double, Triple wall corrugated board
One- or Two-pieces box
1400 stitches per minute
250～750 boxes per hour
Hot melt gluing, PVA gluing, Mixed
Taping

Height adjustable table

Ejector

Semi-automatic feeder

Stacker

High-speed stitching device

Glue Device

Side stopper

Guide Roller

Machine size (mm)

Reinforced cardboard processing size range (mm)

PAC40/48　FULLY AUTOMATIC STITCHER - GLUER

PAC40/48 is a fully automatic stitcher-gluer that can handle single, double, and triple wall corrugated board. It has equipment of a high-speed stitching device that can stitch 1400 stitches per minute and a gluer, it can stitch and glue on one machine. It has also equipment of an auto feeder, auto folder, and auto stacker, so that all processes from paper feeding to stacking of discharged sheets can be performed automatically, making unmanned operation possible.

≪Specification≫
